光パワーメータ購入ガイド
様々な用途に合うように豊富なラインナップを取り揃えております。以下の光パワーメータ(OPMシリーズ)の比較表を参考に最適な測定器を見つけてください。
光パワーメータ(OPMシリーズ)仕様比較一覧
|
Model |
OPM-110 |
OPM-150 |
OPM-160 |
OPM-200 |
|---|---|---|---|---|
|
USB |
Multichannel |
High-speed & Multichannel |
High Performance |
|
 |
 |
 |
 |
|
|
Datasheets |
||||
|
InGaAs Detector (850-1650 nm) |
✔️ |
✔️ |
✔️ |
✔️ |
|
Silicon Detector (400-1100 nm) |
✔️ |
✔️ |
✔️ |
|
|
Power Range (dBm) |
1mm InGaAs 6 to -72 dBm 3mm InGaAs 3 to -72 dBm 5mm InGaAs 0 to -65 dBm 10mm InGaAs 0 to -55 dBm 2mm HP InGaAs 27 to -45 dBm 3mm Si 0 to -65dBm |
1mm InGaAs 6 to -72 dBm 3mm InGaAs 3 to -72 dBm 5mm InGaAs 0 to -65 dBm 10mm InGaAs 0 to -55 dBm 2mm HP InGaAs 27 to -45 dBm 3mm Si 0 to -65 dBm 10mm Si 3 to -50 dBm |
1mm InGaAs 6 to -72 dBm 2mm HP InGaAs 24 to -40 dBm 3mm Si 3 to -65 dBm |
2mm InGaAs 8 to -80 dBm Integrating sphere 30 to -50 dBm |
|
USB |
✔️ |
✔️ |
✔️ |
✔️ |
|
Touch Screen |
|
✔️ |
✔️ |
✔️ |
|
Averaging Time |
50 ms |
10-30 ms |
8 μs |
50 μs |
|
Max channel count |
1 |
24 |
24 |
4 |
|
Ethernet |
|
✔️ |
|
✔️ |
|
Trigger |
|
|
|
✔️ |
|
Analog output |
|
|
|
✔️ |
|
|
Compare OPM models
Get help choosing. Chat with a Specialist >
|
Features |
|
|---|---|
|
InGaAs Detector (850-1650 nm) OPM-110 OPM-150 OPM-160 OPM-200 |
✔️ ✔️ ✔️ ✔️ |
|
Silicon Detector (400-1100 nm) OPM-110 OPM-150 OPM-160 |
✔️ ✔️ ✔️ |
|
Power Range OPM-110 OPM-150 OPM-160 OPM-200 |
(3 to -65 dBm) (3 to -65 dBm) (3 to -65 dBm) (30 to -80 dBm) |
|
USB
OPM-150 OPM-160 OPM-200 |
✔️ ✔️ ✔️ ✔️ |
|
Touch Screen OPM-150 OPM-160 OPM-200 |
✔️ ✔️ |
|
Averaging Time
OPM-110 OPM-150 OPM-160 OPM-200 |
50ms 10-30ms 8 μs |
|
Ethernet OPM-200 |
✔️ |
|
Trigger OPM-200 |
✔️ |
|
Analog output OPM-200 |
✔️ |
